560PSU02 1KGT011900R0001 支持冗余电源配置

Description

ABB 560PSU02 是一款用于RTU560机架的电源装置，其型号为1KGT011900R0001，部件号（P/N）为149601-42001。以下是对该产品的详细介绍：

一、基本参数

• 输入电压：48V至220V直流（允许±20%的偏差）
• 输出电压：提供5V和24V直流两种电压
• 输出功率：足够为最多8个通信单元（CMU）的子机架供电

二、功能特点

1. 冗余配置：支持冗余电源配置，当一台电源出现故障时，另一台可以接管全部负载，提高系统的可靠性。冗余运行时，只能使用相同类型和规格的电源。

2. 保护机制：

   • 输入和输出之间的电位隔离：增强电气安全性。
   • 输出端电子功率限制：防止过载。
   • 输出端短路保护：防止短路对电源和负载的损害。
   • 输入端过压保护：防止输入电压过高对电源的损害。
   • 输入端反向电压保护：防止反向电压接入对电源的损害。

3. 监控与指示：

   • 并联运行，监控冗余电源配置：实时监控电源的运行状态。
   • 冗余运行中的受控负载平衡：优化电源的使用效率。
   • 用于监控输出电压的LED指示灯：方便用户直观了解电源的工作状态。
   • 故障时的报警指示：及时提醒用户处理故障。

4. 其他特点：

   • 自然对流冷却：无需额外的散热设备，降低使用成本。
   • 可承受长达50毫秒的输入电压中断：增强电源的抗干扰能力。

三、应用场景

ABB 560PSU02 电源装置适用于需要高可靠性和稳定性的工业自动化场合，如RTU560子机架560MPR03和560SFR02的供电。

四、价格与购买

ABB 560PSU02 电源装置的价格因购买渠道、数量及供应商的不同而有所差异。根据最新的市场信息，其价格大致在1441.2元至3640.8元之间。建议在购买前与多家供应商联系，获取最准确的报价和交货期信息。

五、注意事项

• 在购买时，请确保选择正规渠道和可靠的供应商，以保证产品的质量和售后服务。
• 在安装和使用时，请遵循产品说明书中的指导，确保正确连接和配置电源装置，以避免潜在的安全风险。

综上所论，ABB 560PSU02 是一款功能强大、性能稳定的电源装置，适用于工业自动化场合的供电需求。

ABB 560PSU02 is a power supply unit for the RTU560 rack, model 1KGT011900R0001, part number (P/N) 149601-4201. The following is a detailed introduction to the product:

1、 Basic parameters
Input voltage: 48V to 220V DC (allowable deviation of ± 20%)
Output voltage: Provides two types of voltage: 5V and 24V DC
Output power: sufficient to power up to 8 communication unit (CMU) sub racks
2、 Functional Features
Redundant configuration: Supports redundant power supply configuration. When one power supply fails, the other can take over all loads, improving the reliability of the system. During redundant operation, only power sources of the same type and specification can be used.
Protection mechanism:
Potential isolation between input and output: enhances electrical safety.
Output end electronic power limit: prevents overload.
Output short circuit protection: prevents damage to the power supply and load caused by short circuits.
Input overvoltage protection: prevents damage to the power supply caused by high input voltage.
Reverse voltage protection at the input end: prevents damage to the power supply caused by reverse voltage connection.
Monitoring and indication:
Parallel operation, monitoring redundant power supply configuration: Real time monitoring of power supply operation status.
Controlled load balancing in redundant operation: optimizing the efficiency of power supply utilization.
LED indicator light for monitoring output voltage: convenient for users to intuitively understand the working status of the power supply.
Alarm indication during malfunction: Promptly remind users to handle the malfunction.
Other features:
Natural convection cooling: No additional heat dissipation equipment is required, reducing usage costs.
Can withstand up to 50 milliseconds of input voltage interruption: enhances the anti-interference ability of the power supply.
3、 Application scenarios
The ABB 560PSU02 power supply unit is suitable for industrial automation applications that require high reliability and stability, such as supplying power to the RTU560 subrack 560MPR03 and 560SFR02.

4、 Price and Purchase
The price of ABB 560PSU02 power supply unit varies depending on the purchasing channel, quantity, and supplier. According to the latest market information, its price is roughly between 1441.2 yuan and 3640.8 yuan. It is recommended to contact multiple suppliers before purchasing to obtain the most accurate quotation and delivery time information.

5、 Precautions
When purchasing, please make sure to choose legitimate channels and reliable suppliers to ensure product quality and after-sales service.
When installing and using, please follow the instructions in the product manual to ensure proper connection and configuration of the power supply device to avoid potential safety risks.
In summary, ABB 560PSU02 is a powerful and stable power supply device suitable for the power supply needs of industrial automation applications.
