Description
GE Multilin 650 Bay Controller（型号：FRONT DISPLAY 189C1337P1R10） 是通用电气（GE）推出的一款用于配电系统监控与控制的设备，广泛应用于电力变电站、工业配电及能源管理系统。以下是该设备的主要技术参数和功能特点：
1. 显示与操作界面
- 显示屏：
- 前置液晶显示屏（LCD），支持中英文菜单操作。
- 显示内容：电压、电流、功率、频率、故障信息、设备状态等。
- 显示分辨率：高对比度，适应不同光照环境。
- 操作界面：
- 按键或触摸屏操作（具体视配置而定）。
- 支持本地和远程参数设置与调试。
2. 输入/输出（I/O）参数
- 模拟量输入：
- 支持电压、电流、功率因数等模拟信号采集。
- 输入范围：可配置，适应不同传感器。
- 数字量输入/输出：
- 数字量输入（DI）：用于监测断路器状态、开关位置等。
- 数字量输出（DO）：用于控制报警、跳闸等。
- 通信接口：
- 支持多种通信协议，如 Modbus、DNP3、IEC 61850 等。
- 通信接口类型：RS-485、以太网（可选）。
3. 保护与控制功能
- 保护功能：
- 过电流保护、欠电压保护、过电压保护、频率保护等。
- 支持多级保护逻辑，可自定义保护阈值。
- 控制功能：
- 断路器控制（合闸、分闸）。
- 自动重合闸功能。
- 负载管理（如负荷切换）。
4. 性能参数
- 工作环境：
- 温度范围：-20°C 至 +70°C（具体视型号而定）。
- 湿度范围：5% 至 95%（无凝露）。
- 电源要求：
- 输入电压：AC/DC 24V 至 240V（宽电压范围）。
- 功耗：低功耗设计，适应节能需求。
- 电磁兼容性（EMC）：
- 符合国际 EMC 标准，抗干扰能力强。
5. 扩展性与兼容性
- 扩展模块：
- 支持多种扩展模块，如增加 I/O 点数、通信接口等。
- 兼容性：
- 可与 GE Multilin 系列其他设备无缝集成。
- 支持第三方系统集成（如 SCADA、DCS 等）。
6. 安全与认证
- 安全标准：
- 符合国际安全标准（如 IEC、UL、CE 等）。
- 认证：
- 通过相关行业认证，确保产品质量与可靠性。
7. 应用场景
- 电力变电站：用于中低压配电系统的监控与保护。
- 工业配电：适用于工厂、矿山等工业场所的配电系统。
- 能源管理：支持能源数据采集与分析，优化能源使用效率。
8. 软件与配置
- 配置软件：
- 提供专用配置软件，支持参数设置、事件记录查看、固件升级等。
- 事件记录：
- 支持事件记录与故障录波，便于故障分析与排查。
注意事项
- 实际技术参数可能因具体型号或配置不同而有所差异，建议参考产品手册或联系 GE 官方获取详细信息。
- 安装与调试需由专业人员完成，确保设备正常运行与安全性。The GE Multilin 650 Bay Controller (model: FRONT LAY 18971337P1R10) is a device launched by General Electric (GE) for monitoring and controlling distribution systems, widely used in power substations, industrial distribution, and energy management systems. The following are the main technical parameters and functional features of the device:
1. Display and operation interface
display:
Front LCD display screen, supporting menu operations in both Chinese and English.
Display content: voltage, current, power, frequency, fault information, equipment status, etc.
Display resolution: high contrast, suitable for different lighting environments.
Operation interface:
Button or touchscreen operation (depending on configuration).
Support local and remote parameter settings and debugging.
2. Input/Output (I/O) Parameters
Analog input:
Support the acquisition of analog signals such as voltage, current, and power factor.
Input range: configurable, suitable for different sensors.
Digital input/output:
Digital input (DI): used to monitor the status of circuit breakers, switch positions, etc.
Digital output (DO): used to control alarms, trips, etc.
Communication interface:
Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850, etc.
Communication interface type: RS-485、 Ethernet (optional).
3. Protection and control functions
Protection function:
Overcurrent protection, undervoltage protection, overvoltage protection, frequency protection, etc.
Support multi-level protection logic and customizable protection thresholds.
Control function:
Circuit breaker control (closing and opening).
Automatic reclosing function.
Load management (such as load switching).
4. Performance parameters
Work environment:
Temperature range:- 20 ° C to+70 ° C (depending on the model).
Humidity range: 5% to 95% (no condensation).
Power requirements:
Input voltage: AC/DC 24V to 240V (wide voltage range).
Power consumption: Low power design, suitable for energy-saving needs.
Electromagnetic compatibility (EMC):
Compliant with international EMC standards, with strong anti-interference ability.
5. Scalability and compatibility
Expansion module:
Support multiple expansion modules, such as increasing I/O points, communication interfaces, etc.
compatibility:
Seamless integration with other devices in the GE Multilin series.
Support third-party system integration (such as SCADA, DCS, etc.).
6. Security and authentication
Safety standards:
Compliant with international safety standards such as IEC, UL, CE, etc.
authentication:
Ensure product quality and reliability through relevant industry certifications.
7. Application scenarios
Power substation: used for monitoring and protection of medium and low voltage distribution systems.
Industrial power distribution: Suitable for power distribution systems in industrial places such as factories and mines.
Energy Management: Support energy data collection and analysis to optimize energy efficiency.
8. Software and Configuration
Configure software:
Provide dedicated configuration software that supports parameter settings, event log viewing, firmware upgrades, and more.
Event record:
Support event recording and fault waveform recording for easy fault analysis and troubleshooting.
precautions
Actual technical parameters may vary depending on specific models or configurations. It is recommended to refer to the product manual or contact GE official for detailed information.
Installation and debugging must be completed by professionals to ensure the normal operation and safety of the equipment.
