The FSS system is a comprehensive engineering project that integrates design management, simulation technology, computer technology, and nuclear power engineering knowledge. Adopting an integrated simulation support platform, supporting online model modification and debugging, with comprehensive database management functions, simulation operation management functions, as well as I/O and network control functions. It is mainly used to train nuclear power operators, improve the quality and ability of nuclear power plant operators, and is the key to ensuring the safe and reliable operation of nuclear power plants. Simulation systems are also an important verification tool for improving power plant design and changing operating procedures.
System Usage (Nuclear Power Plant Full Range Simulator)
● Effectively train operators
Conduct an operation permit exam
Provide support for periodic emergency drills for power plants in accordance with the requirements of the National Nuclear Safety Administration
● Learn, verify, and confirm the design and modification of the power plant I&C system (V&V platform), including: computer-based human-machine interface in the control room, process control functions, power plant operation/emergency procedures, optimization of power plant control and operation, analysis of power plant transients, etc
System characteristics (non safety level DCS simulator)
Adopting Stimulation and Simulation methods, achieving identical human-machine interface and DCS functions for easy maintenance
Store and load ICs quickly, taking no more than 1 minute
● Provide IC management tools that are compatible with the original generated ICs when upgrading DCS application software
● Support comprehensive playback functions, including operating playback on the human-machine interface
● Support fault simulation function, which can simulate all faults supported by actual DCS
Red River Nuclear Power Plant 1-4 × 1000MW Full Range Simulator (FSS)
Ningde Nuclear Power Plant 3, 4, 2 × 1000MW Full Range Simulator (FSS)
